Diamondback Release 4C Carbon

Diamondback Release 4C Carbon
  • Color: Matte Olive Green
  • Color: Red
$3,599.99 - $4,000.00
Please select options
This item is not permitted to be shipped, however it can be purchased online and picked up at your convenience.

Details

The Release 4C features the same bottomless-feeling rear suspension and deft handling as our aluminum Release models, but with an even lighter, stiffer chassis built from carbon fiber. It starts with our Level Link suspension system, which isolates chain forces from trail inputs. This means the suspension doesn't bob when you stomp on the pedals, yet becomes extremely plush on technical descents.

For smooth bump-eating performance, the Release 4C is equipped with a Fox Float DPS EVOL LV rear shock and a 150mm travel Fox 34 Performance Float fork. SRAM's NX Eagle 12-speed single-ring drivetrain provides consistent shifting and, thanks to its 50-tooth granny gear, makes short work of pesky climbs. SRAM Guide R brakes keep you slicing through the most technical lines all day long.

- Level Link design equals 130mm of efficient yet supple rear suspension
- Light and stiff carbon frame with Boost 148x12mm Maxle dropout
- KS LEV Si dropper post (w/ Southpaw remote lever) adds maneuverability on descents
- Fox 34 Performance Float and Fox Float DPS EVOL LV rear shock provide supple suspension travel (150/130mm, front and rear)
- Plenty of gearing to tackle steep climbs, thanks to SRAM NX Eagle 11-50T, single-ring drivetrain

Dropper posts

A dropper seatpost allows you to quickly lower and raise your seat to give you an ideal riding position. Dropping your seat creates a lower center of gravity for better control and maneuverability on steep descents, while raising it puts you at normal riding height for efficient pedaling.

Construction can include either hydraulic- or cable-actuated systems and the post’s travel can either be infinitely adjustable or stopped at set intervals, depending on the model.

Dropper seatposts come in standard lengths and diameters and vary by the amount of travel.

Specs

Frame Carbon Release 27.5, Monocoque Carbon Front and Rear Triangle, 130mm Travel, Level Link Suspension Platform, Euro Standard Threaded BB, ISCG-05 Tabs, Maxle Drop Out, 1.5" Tapered Headtube, Post Mount Disc Tabs
Fork Fox 34 Performance Float, 27.5", 150mm Travel, Grip 3 Position Dampener, Rebound Adjust, 1.5" Tapered Steerer
Headset FSA No. 57 Sealed Cartridge
Rear Shock Fox Float DPS EVOL LV, Performance, 3 Position Lever, 200x57mm, 22.2mm Eyelet Width
Axles Front: 110 x 15mm Boost thru-axle
Rear: 148 x 12mm Boost thru-axle
Rims/Wheels Diamondback Blanchard 28R, Tubeless Ready, 32h
Hubs Front: 32h Alloy, Sealed Cartridge Bearing
Rear: 32h Alloy, 5 Sealed Cartridge Bearing, Cassette
Spokes 14g Stainless Steel
Tires Front: Maxxis Minion DHF 27.5x2.3" EXO, TLR, Folding
Rear: Maxxis Minion DHR 27.5x2.3" EXO, TLR, Folding
Crankset SRAM Descendant 6K Eagle
Chainrings 32T Direct Mount
Bottom Bracket SRAM DUB Outboard Bearing
Chain SRAM NX Eagle, 12 Speed
Rear Derailleur SRAM NX Eagle, 12 Speed
Cassette/Rear Cogs SRAM PG-1230 Eagle, 12 Speed, 11-50T
Shifters SRAM NX Eagle, 12 Speed
Handlebars DB35 Alloy, 780mm Wide, 15mm Rise, 35mm Bar Bore
Tape/Grips Ergon GE10 Evo Lock-On
Stem DB35 Alloy, 40mm Reach, 35mm Bar Bore
Brake Levers SRAM Guide R
Brakes SRAM Guide R, w/180mm Front /180mm Rear Centerline Rotors
Pedals DB CNC Platform, Sealed Cartidge Bearing w/Replaceable Pins
Saddle WTB Volt Race
Seat Post KS LEV SI Internal Dropper, w/SouthPaw Remote, 31.6mm, XS/SM = 125mm, MD/LG/XL = 150mm
Accessories & Extras Owner's Manual, Assembly Guide, Tool Kit, RD Hanger, Shock Pump, Fork Mud Guard

* Subject to change without notice.

Part Numbers

Option UPC MPN Store SKU
Matte Olive Green / Small 791964574071 02-0220110
Matte Olive Green / Medium 791964574088 02-0220111
Matte Olive Green / Large 791964574095 02-0220112 791964574095
Matte Olive Green / X-Large 791964574101 02-0220113 791964574101
Red / Small 791964576495 02-0220025
Red / Medium 791964576501 02-0220026
Red / Large 791964576518 02-0220027
