Details
The full-day, full-gas performance of the Synapse, outfitted for more. Big tires, wide rims and even wider gearing let you get after it on roads others fear to tread. SmartForm C2 Alloy Construction and carbon blade forks deliver exceptionally low weight for this category for a high-performance feel. The endurance geometry provides stable, confident handling, and a more upright riding position for all-day adventures, while Micro-Suspension in the rear triangle and fork to keep you comfortable and in control. Clearance for tires up to a 32mm wide, and subtle, hidden fender mounts for exploring the wilder side of endurance riding.
Specs
Frame | Synapse Disc Asymmetric, SmartForm C2 Alloy, SAVE, BB30, flat mount |
---|---|
Fork | Synapse Disc Asymmetric, SAVE, Full Carbon, 1-1/8" - 1 1/4" tapered steerer, flat mount, 55mm rake |
Headset | FSA Integrated, 1-1/4" lower bearing, 25mm top cap |
Axles |
Front: 12 x 100mm Rear: QR |
Wheels/Rims | WTB ST i19, 28h, tubeless ready |
Hubs |
Front: Formula RX-512 Rear: CX-22 |
Spokes | Stainless Steel, 14g |
Tires | WTB Exposure TCS, 700 x 30c, tubeless ready |
Crankset | Cannondale Si |
Chainrings | 48/32 |
Bottom Bracket | Cannondale BB30 |
Chain | KMC X11, 11-speed |
Front Derailleur | Shimano 105, braze-on |
Rear Derailleur | Shimano 105 GS |
Cassette/Rear Cogs | Shimano 105, 11-34, 11-speed |
Shifters | Shimano 105, 2x11 |
Handlebars | Cannondale C3, 6061 Alloy, Compact |
Tape/Grips | Cannondale Grip Bar Tape w/Gel, 3.5mm |
Stem | Cannondale C3, 6061 Alloy, 31.8, 7° |
Brake Levers | Shimano 105 7000 |
Brakes | Tektro Spyre-C cable actuated disc, 160/160mm |
Pedals | Wellgo w/ Clip and Strap |
Saddle | Fabric Scoop Radius Sport, steel rails |
Seat Post | Cannondale C3, 6061 Alloy, 25.4 x 350mm (44-56), 400mm (58-61) |
* Subject to change without notice.
Part Numbers
Option | UPC | MPN |
---|---|---|
Vulcan / 48cm | 884603717004 | C12339M3048 |
Vulcan / 51cm | 884603717011 | C12339M3051 |
Vulcan / 54cm | 884603717028 | C12339M3054 |
Vulcan / 56cm | 884603717035 | C12339M3056 |
Vulcan / 58cm | 884603717042 | C12339M3058 |
Vulcan / 61cm | 884603717059 | C12339M3061 |
